Arc welding and handling robot, featuring an integrated cable routing design, is engineered to handle all welding tasks and payloads up to 6 kg. By delivering higher process speeds and shorter cycle times, the FD-B6 meets the rigorous requirements of even the most demanding handling applications.
The new FD-B6 (6kg payload) features integrated cabling and pre-installed SynchroFeed connections, delivering high-speed performance and shorter cycle times for demanding welding tasks.
| Type | FD-B6L |
|---|---|
| Number of axes | 6 |
| Working range | R 2008 mm |
| Max. payload capacity | 6 Kg |
| Additional payload capacity Axis 3 | 20 Kg |
| Protection class upper arm | IP65 equivalent (J5, J6 Axis) |
| Installation type | Floor, Wall, Ceiling |
| Weight | 278 Kg |
